DUAL is Hunter’s new two-wire plug-in for the I-Core controller.
Designed to bring the convenience and efficiency of two-wire technology to all, the DUAL system can operate up to 48 zones via a single pair of wires, at distances up to 7,500 feet (2.3 km). The 48 zones can all be installed on a single path or divided over multiple paths to take advantage of pipe trenches. Because it only requires two wires, DUAL offers unmatchable savings in labour, wire, and money. Since it’s I-Core compatible, system operators still receive advanced features and benefits like flow monitoring, quick system overview access, a factory-installed SmartPort®, six language capability, and a bold, graphic display.
- Decoder station sizes available: 2
- Max. recommended distance, decoder to solenoid: 100 ft
- DUAL-S external surge protection modules
- Max. distance to decoder, 14 AWG wire path: 5,000 ft; 12 AWG wire path 7,500 ft.
- Field programmable
- DUAL decoder module display and push button programming makes it easy to program decoders at the controller itself
- DUAL decoders can be field programmed with the Hunter ICD-HP. No need to remove decoders from the two-wire path
- Decoder module displays decoder operation and diagnostic information
- Can operate up to 48 stations of combined decoder and conventional control making system retrofit easy
- Waterproof connectors for connection to two-wire path supplied with all DUAL decoders and DUAL-S surge protection
- Number of 2-wire paths: 3
