Technical
Rated flow: 4 m Rated head: 46 m Primary shaft seal BBVP Approvals: CE,WM,C-TICK Curve tolerance:ISO9906:2012 3B Pump version: A Adjustable start pressure: N Start pressure: 1.5 bar Rated speed: 2800 rpm
Materials
Pump housing: Stainless steel EN 1.4301 / AISI 304 Impeller: Composite Material code: A
Installation
Minimum ambient temperature: 0 Max. ambient: 40 Maximum operating pressure: PN 6 bar Pump inlet: G 1 Pump outlet: G 1
Liquid
Pumped liquid: Water Liquid temperature range: 0. 40 Selected liquid temperature: 20 Density: 998.2 kg/m
Electrical data
Power input - P1: 1130 W Rated power - P2: 0.746 kW Mains frequency: 50 Hz Rated voltage: 1 x 230 V Rated current: 5.1 A Starting current: 17.8 A Rated speed: 2800 rpm Capacitor size - run: 16 µF/450 V Enclosure class (IEC 34-5): IP44 Insulation class (IEC 85): F Length of cable: 1.5 m Type of cable plug: AUS
