Applications:
Ideal for domestic irrigation from shallow wells or sand spears, overhead or high tank filling, pressure boosting and water transfer.
Features & Benefits
Pump
• Single stage jet assisted centrifugal with closed vane impeller
• Brass pump shaft sleeve
• Mechanical shaft seal
Motor
• Davey manufactured
• 2 pole, 2850rpm, 50Hz
• TEFC with IP55 enclosure
• Class F insulation
• Permanently split capacitor design
• Double contact sealed C3-HTG rated ball bearings
• Protected against both high operating temperatures and high current by a built-in automatically resetting thermal overload
• All models supplied with 2m long power lead fitted with Australian 3 pin plug
• Manufactured from highest quality corrosion resistant materials
• Compact foot print for quick and easy installation
• TEFC motor - corrosion resistant and excludes dust and dirt
• Motor and pump designed for frequent starts
• Every unit individually tested to guarantee reliable operation
• Low maintenance
• Easy to service if required
• Reliable and proven performance
Please refer to the documentation for all features and full technical specifications.
DYNAJET DATA SHEET
